Specification
Features
- Powered by an 11th generation Intel
Celeron processor - Fanless design, using a large-area
uniform heating fin - Dual-band Wi-Fi, Bluetooth 5.0, and
expandable 4G (M.2 interface) - 10.1-inch flat capacitive touch panel is
impact-resistant - Rich interfaces, including multiple USB/LAN
/HDMI and other I/O ports - Wide voltage and temperature design, IP65-rated
dustproof and waterproof
| Durability | Front Panel IP65 compliant 8kV contact discharge, ±15kV air discharge |
| Security | Integrated TPM2.0 |
| Operating System | Windows 11 Home Optional: Windows 11 pro |
| Processor | Intel N5100 (4MB Cache, up to 2.8GHz, 4 Cores, 4 Threads TDP 6W) |
| Graphics | Intel® UHD Graphics |
| Memory | 8GB LPDDR4x on board |
| Storage | 128GB SATA SSD Optional 256GB/512GB PCIe SSD |
| Display | 10.1", HD (800x1280), 700 Nits 10 point capacitive touch screen |
| Audio | Optional 2W speaker |
| Keyboard & Input | Power key x1 |
| Network & Connectivity | Intel® Wi-Fi 5 9461 (802.11 ac) Bluetooth® V5.0 Optional 4G LTE LTE-FDD: B1/3/5/7/8/20 LTE-TDD: B40 WCDMA: B1/5/8 GSM: 900/1800 China (China Unicom, China Telecom, China Mobile), Europe, Middle East, Africa, Taiwan, Japan |
| I/O Interface | SIM card x 1 USB3.0 (typeA) x 2 USB2.0 (typeA) x 2 3.5mm AudioJack x 1 HDMI 2.0a typeA x 1 10/100/1000 Ethernet (RJ45) x 2 Serial port (RS232: D-sub, 9-pin) x 2 Optional RS232 x 1/RS485 x 1 DC5.5mm-In jack x 1 (support 12-24V) SMA x 2 |
| Battery & Charging | AC adapter: 100-240V, 50Hz-60Hz, 48W Separated 3V/220mAh RTC |
| Environment | Operating temperature: -20°C to 60°C (-4"F~140"F) Storage tmperature: -30°C to 70°C ( -22°F-158°F) Humidity: 95% Non-Condensing |
| Dimension | 257.2 mm (L) x 170 mm (W) x 45.95 mm (H) |
| Weight | 1.2 kg |
| Accessories | Standard: Adapter, Hook Assembly, Antenna |
| Warranty | One-year limited warranty standard |
